B03 – Perforated Screen Panel
- Uniform Perforated Screening Surface: Regularly distributed openings provide consistent particle separation and classification across the active screening area.
- Rigid Panel Construction: The solid panel body supports repeated vibration and material loading while maintaining a stable screening surface during industrial operation.
- Integrated Mounting Positions: Recessed corner mounting areas allow secure installation on compatible vibrating screen decks and simplify panel replacement during maintenance.
- Suitable for Fine to Medium Screening: Designed for classification of granular bulk materials where controlled aperture size and stable screening performance are required.
1. Product Overview
The B03 Perforated Screen Panel is a replaceable screening component designed for vibrating screens and industrial material-classification equipment. The panel uses a flat perforated surface with regularly arranged openings that allow undersize particles to pass through while larger material remains above the screen deck. Integrated mounting areas positioned near the panel corners provide practical attachment to the supporting screen structure. This type of screen panel is suitable for mineral processing, aggregate production, building materials, metallurgy, chemical processing, and other bulk-material applications where controlled particle separation and repeatable screening performance are required.
2. Detailed Description
During operation, material is distributed over the perforated panel while vibration from the screening machine moves the particles across the surface. Particles smaller than the selected aperture size pass through the openings, while oversized particles continue toward the discharge section. The regular perforation pattern helps provide consistent separation throughout the screening area.
The B03 panel features an integrated plate-style body with multiple perforated sections and recessed mounting locations. Individual panels can be installed across the screen deck according to the equipment dimensions and required screening area. The replaceable panel arrangement allows selected sections to be removed for inspection or replacement without changing the entire screening surface, making it suitable for continuous industrial classification and grading systems.
3. Why Choose Us
- Consistent particle classification: Uniformly arranged perforations help maintain stable separation performance across the working screen surface.
- Rigid screening structure: The integrated panel body provides a stable surface for repeated vibration and bulk-material loading.
- Replaceable modular design: Individual panels can be removed and replaced according to maintenance requirements, reducing unnecessary replacement of the full screen deck.
- Secure mounting arrangement: Recessed installation positions provide defined fastening points for connection to compatible vibrating screen structures.
- Suitable for multiple bulk materials: Applicable to granular materials in mineral processing, aggregates, building materials, and other industrial screening operations.
- Easy screen-deck integration: Multiple perforated panels can be arranged together to match different screening machine dimensions and deck configurations.
- Flexible aperture selection: Screening opening size can be selected according to the required particle classification specification.
| Parameter | Specification |
|---|---|
| Model | B03 |
| Product Type | Perforated Screen Panel |
| Screening Structure | Perforated Panel Type |
| Aperture Arrangement | Uniformly Distributed Openings |
| Panel Length (mm) | — |
| Panel Width (mm) | — |
| Panel Thickness (mm) | — |
| Aperture Size (mm) | — |
| Aperture Shape | — |
| Open Area (%) | — |
| Material | — |
| Mounting Type | Recessed Mechanical Mounting |
| Weight (kg) | — |
| Typical Applications | Vibrating screens, grading equipment and bulk-material classification systems |
