B10 – Comb-Type Screen Panel
- Comb-Type Screening Structure: Repeated tooth-shaped screening elements form open passages for separating bulk materials while maintaining a rigid working surface on industrial vibrating screens.
- Efficient Coarse Material Separation: The open comb arrangement allows undersize particles to pass through while larger particles continue across the screen deck toward the discharge section.
- Reduced Material Lodging: Tapered and staggered screening openings help provide a less restrictive passage for irregular particles compared with conventional straight perforated surfaces.
- Replaceable Modular Panel: The framed panel structure allows individual screen sections to be installed, inspected, and replaced within compatible vibrating screen decks.
1. Product Overview
The B10 Comb-Type Screen Panel is an industrial screening component designed for vibrating screens and bulk-material classification equipment. Its working surface consists of repeated comb-like or tooth-shaped elements that create open screening passages across the panel. During operation, smaller particles pass through these openings while oversized material remains on the surface and moves toward the discharge end. The panel is suitable for coarse screening, scalping, pre-screening, and classification of granular or lump bulk materials. Typical applications include mineral processing, aggregate production, building materials, metallurgy, and other industrial material-handling systems where an open and rigid screening surface is required.
2. Detailed Description
When installed on a vibrating screen, the B10 panel receives material directly on its comb-type working surface. Machine vibration moves the material across the deck, allowing particles smaller than the selected screening openings to fall through while larger particles continue along the screening direction. The tapered tooth arrangement and relatively open passages can help reduce particle wedging in coarse screening applications.
The panel uses a rigid framed structure with repeated screening elements arranged in rows. Depending on the specific configuration, the screening openings may be formed by staggered or directional tooth profiles. Multiple panels can be installed together to form the complete screen deck. Panel dimensions, opening size, tooth spacing, and mounting arrangement can be matched to the vibrating screen and required particle separation duty.
3. Why Choose Us
- Open screening structure: Comb-shaped elements provide clear passages for undersize particles and support continuous bulk-material flow across the deck.
- Suitable for coarse screening: The rigid tooth-type configuration is appropriate for scalping, pre-screening, and classification of larger granular or lump materials.
- Reduced particle wedging: Tapered screening passages can help decrease material lodging compared with some conventional straight-sided openings.
- Rigid panel construction: The framed layout supports the screening elements and helps maintain structural stability during repeated vibrating operation.
- Replaceable screen section: Individual panels can be removed for inspection or replacement without necessarily changing the complete screening deck.
- Flexible deck arrangement: Multiple comb-type panels can be configured according to screen width, deck length, and process requirements.
- Easy equipment integration: Suitable for installation on compatible vibrating screens used in mineral, aggregate, building-material, and bulk-processing lines.
| Parameter | Specification |
|---|---|
| Model | B10 |
| Product Type | Comb-Type Screen Panel |
| Screening Structure | Comb / Tooth-Type Panel |
| Opening Configuration | Tapered / Staggered Screening Passages |
| Panel Length (mm) | — |
| Panel Width (mm) | — |
| Panel Height (mm) | — |
| Screen Opening (mm) | — |
| Tooth Spacing (mm) | — |
| Panel Thickness (mm) | — |
| Material | — |
| Mounting Type | Framed Mechanical Mounting |
| Weight (kg) | — |
| Typical Applications | Coarse screening, scalping, pre-screening and bulk-material classification |
